Simple jQuery Accordion Slider Plugin - mSlide

mSlide is a simple and touch enabled jQuery plugin for easily creating an horizontal accordion Slider which supports any html elements (div, image, etc...).

How to use it:

1. Include jQuery library, jQuery ui and jQuery mSlide plugin on the page

<script src="http://code.jquery.com/jquery.min.js" type="text/javascript"></script>
<script src="http://code.jquery.com/ui/1.10.2/jquery-ui.min.js" type="text/javascript"></script>
<script src="jquery.mSlide.js" type="text/javascript"></script>

2. Create the slider html with some control buttons

<div id="gallery" style="width:400px; height:280px;">
<div class="slide" style="width:400px; height:280px; background:#fa0;"> Slide 1 </div>
<div class="slide" style="width:250px; height:280px; background:#f0a;"> Slide 2 </div>
<div class="slide" style="width:350px; height:280px; background:#fa0;"> Slide 3 </div>
<div class="slide" style="width:310px; height:280px; background:#f0a;"> Slide 4 </div>
<div class="slide" style="width:370px; height:280px; background:#fa0;"> Slide 5 </div>
<div class="slide" style="width:370px; height:280px; background:#f0a;"> Slide 6 </div>
</div>
<a id="first">first</a> || <a id="prev">prev</a> || <a id="next">next</a> || <a id="last">last</a><br />
<a id="slide_num">Show Slide 4</a>

3. The CSS for control buttons

div.mSlide_btnLeft {
width: 5%;
height: 100%;
position: absolute;
left: 0;
top: 0;
background: #000;
z-index: 100;
opacity: .5;
}
div.mSlide_btnRight {
width: 5%;
height: 100%;
position: absolute;
right: 0;
top: 0;
background: #000;
z-index: 100;
opacity: .5;
}

4. Call the plugin with options

<script type="text/javascript">

$(document).ready(function(){
$('#gallery').mSlide({
'change': function(e, pos_x) {
/* onChange - callback */
},
'slideMarginLeft' : 50 /* 50px from left (used for left control) */
});

$('#next').click(function(){
$('#gallery').mSlide('slideNext');
});

$('#prev').click(function(){
$('#gallery').mSlide('slidePrev');
});

$('#last').click(function(){
$('#gallery').mSlide('slideTo','last');
});

$('#first').click(function(){
$('#gallery').mSlide('slideTo','first');
});

$('#slide_num').click(function(){
$('#gallery').mSlide('slideTo',3);
});

});
</script>

This awesome jQuery plugin is developed by dlehmann. For more Advanced Usages, please check the demo page or visit the official website.
