Created by Sebastian Helzle

This is a jQuery plugin for displaying tooltips.
There are a lot of other plugins for this task, but they didn't meet our
various requirements at Small Improvements.

So finally we decided to create our own plugin and wanted to share it with you!


Download smallipop now   Visit smallipop at github




Create a smallipop

Here is the easiest way to create a smallipop

<a class="myElement" href="#" title="That was easy!">Hover me!</a>

<script type="text/javascript">
    $('.myElement').smallipop();
</script>

If you like some markup as tooltip, you can do that as well

Hover me! Give me some markup
<span class="smallipop">
    Hover me!
    <span class="smallipopHint">
        <b>Give me some markup!</b>
    </span>
</span>

You can provide the content for the bubble via javascript too

<a href="#" id="tipcustomhint" title="I'm the old title">
    Hover me!
</a>

<script type="text/javascript">
    $('#tipcustomhint').smallipop({}, "I'm the real hint!");
</script>

There are cases when the trigger is replaced or changed when clicked and the tooltip needs to be hidden

<div id="sampleContainer">
    <a href="#" id="tipkiller" class="smallipop" title="Click the link and I will be gone">
        Hover me!
    </a>
</div>

<script type="text/javascript">
    $('#tipkiller').click(function(e) {
        e.preventDefault();
        $('#sampleContainer').html('<div>Some new content</div>');
    });
</script>

Elements can be positioned everywhere, smallipop will be at the right position

Look to the right
Hover me! Markuptip with very long text
and a link with some javascript which replaces the trigger

<div class="smallipop">
    Hover me!
    <span class="smallipopHint">
        <b>Markuptip with very long text</b><br/>
        ...
    </span>
</div>

How about showing the bubble on the left or right of an element?

Hover me! Good for dropdowns! Or me! Auto align when there's no room on the right.
<span class="smallipopHorizontal">
    Hover me!
    <span class="smallipopHint">
        Good for dropdowns!
    </span>
</span>

<script type="text/javascript">
    $('.smallipopHorizontal').smallipop({
        preferredPosition: right,
        theme: 'black',
        popupOffset: 10,
        invertAnimation: true
    });
</script>

Don't like animations? No Problem!

<a class="smallipopStatic" title="Doesn't move an inch">
    Hover me!
</a>

<script type="text/javascript">
    $('.smallipopStatic').smallipop({
        theme: 'black',
        popupDistance: 0,
        popupYOffset: -14,
        popupAnimationSpeed: 100
    });
</script>

Change default positioning

<a class="smallipopStatic" title="Below when possible">
    Hover me!
</a>

<script type="text/javascript">
    $('.smallipopBottom').smallipop({
        theme: 'black',
        preferredPosition: 'bottom'
    });
</script>
Special support for form elements

Smallipop will appear when form elements are focused and stay even when the mouse leaves the input.









<input class="smallipopInput" type="text" size="30" title="Enter some text"/>

<script type="text/javascript">
    $('.smallipopInput').smallipop({
        preferredPosition: right,
        theme: 'black',
        popupOffset: 0,
        triggerOnClick: true
    });
</script>
Image with absolute positioned hints

Hints can be positioned anywhere, even on absolute positioned or floating elements.

Bird in china
+

Black hole sun
+

The bird is the word

This bubble has a white theme extended by another sub theme 'transparent'.

Also the trigger is made out of pure css.
arrow
It's a house!

It has an image as trigger.
We have provided some you can use in the images folder.
<script type="text/javascript">
    $('.myElement').smallipop({
        hideTrigger: true, // Trigger is hidden when the bubble is shown
        theme: 'white whiteTransparent', // White theme is used with it's transparent extension
        popupYOffset: 20, // Bubble has a 20px vertical offset
        popupDistance: 30, // Bubble travels vertically by 30px when fading in
        popupOffset: 0, // No horizontal offset
    });
</script>
Text with inline hints

Something completely different

Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt Some info about invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua. At vero eos et accusam et justo duo dolores et ea rebum. Stet clita kasd gubergren, no sea takimata sanctus est Lorem ipsum dolor sit amet.

Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua. At vero eos et accusam

accusam

Bird in china

Sed ut perspiciatis unde omnis iste natus error sit voluptatem accusantium doloremque laudantium, totam rem aperiam, eaque ipsa quae ab illo inventore veritatis et quasi architecto beatae vitae dicta sunt explicabo. Nemo enim ipsam voluptatem quia voluptas sit aspernatur aut odit aut fugit, sed quia consequuntur magni dolores eos qui ratione voluptatem sequi nesciunt.

Neque porro quisquam est, qui dolorem ipsum quia dolor sit amet, consectetur, adipisci velit, sed quia non numquam eius modi tempora incidunt ut labore et dolore magnam aliquam quaerat voluptatem. Ut enim ad minima veniam, quis nostrum exercitationem ullam corporis suscipit laboriosam, nisi ut aliquid ex ea commodi consequatur? Quis autem vel eum iure reprehenderit qui in ea voluptate velit esse quam nihil molestiae consequatur, vel illum qui dolorem eum fugiat quo voluptas nulla pariatur?

et justo duo dolores et ea rebum. Stet clita kasd gubergren, no sea takimata sanctus est Lorem ipsum dolor sit amet.
<p>
    Some long <span class="smallipop">text</span>...

    And more with a more
    <span class="smallipop">
        complex
        <span class="smallipopHint">
            Some really important hint about the word <b>complex</b>
        </span>
    </span>
    hint...
</p>

<script type="text/javascript">
    $('.smallipop').smallipop();
</script>

Tours
Click to start the tour

This is the second step of the example
<span class="smallipopTour" data-smallipop-tour-index="1">Step 1</span>
<span class="smallipopTour" data-smallipop-tour-index="2">Step 2</span>
<span class="smallipopTour" data-smallipop-tour-index="3" data-smallipop-preferred-position="right">Step 3</span>
<span class="smallipopTour" data-smallipop-tour-index="10">Step 4</span>

<script type="text/javascript">
    $('.smallipopTour').smallipop();
</script>

Advanced configuration

Change content on the fly and use callbacks
<a id="tipChangeContent" title="Change">
    Hover me!
</a>

<script type="text/javascript">
    $('#tipChangeContent').smallipop({
        onAfterShow: function(trigger) {
            $.smallipop.setContent("I'm the new content and replaced the old boring content!");
        },
        onBeforeHide: function(trigger) {
            $.smallipop.setContent("Bye bye");
        }
    });
</script>
Use referenced element as tooltip content
Hover me!

The real tooltip content!
<a id="tipReferenced" data-smallipop-referenced-content="#tipReferencedTarget" title="Referenced content">
    Hover me!
</a>
<div id="tipReferencedTarget">
    The real tooltip content!
</div>

<script type="text/javascript">
    $('#tipReferenced').smallipop();
</script>
Use css animations

Example powered by Animate.css

These effects will only work if your browser support css animations.
When the Modernizr library is used and the browser doesn't support css animations the jQuery animations will be used as fallback.

<a id="tipCSSAnimated" title="Fancy">
    Hover me!
</a>

<script type="text/javascript">
    $('#tipCSSAnimated').smallipop({
        cssAnimations: {
            enabled: true,
            show: 'animated bounceInDown',
            hide: 'animated hinge'
        }
    });
</script>
Hide on click specials
Tip won't hide when clicking the trigger Hover me!

Tip wont't hide when clicking into the popup Hover me! Markuptip with very long text
and a link which doesn't hide the popup
<a id="tipDontHideOnTriggerClick" title="Change">
    Hover me!
</a>

<a id="tipDontHideOnContentClick" title="Change">
    Hover me!
    <span class="smallipopHint">
        <b>Markuptip with very long text</b><br/>
        <a href="#" onclick="return false;">
            and a link which doesn't hide the popup
        </a>
    </span>
</a>

<script type="text/javascript">
    $('#tipDontHideOnTriggerClick').smallipop({
        hideOnTriggerClick: false
    });
    $('#tipDontHideOnContentClick').smallipop({
        hideOnPopupClick: false
    });
</script>

Themes:

Hover the links to see the different themes

Default theme  -  Blue theme  -  Black theme  -  White theme  -  Orange theme
You can extend a theme with an extension theme Hover me! Look at this fat shadow!
<script type="text/javascript">
    $('.myElement').smallipop({
        theme: 'blue fatShadow'
    });
</script>

This allows you to have one basic theme and several subthemes with different border styles or colors for example.

The css for the extension theme looks like this:

#smallipop.fatShadow {
  -webkit-box-shadow: 0 2px 20px rgba(0, 0, 0, 0.8);
     -moz-box-shadow: 0 2px 20px rgba(0, 0, 0, 0.8);
          box-shadow: 0 2px 20px rgba(0, 0, 0, 0.8);
}

Options

You can customize each smallipop with a lot of options and callbacks.
Most of the options can be defined via the html data attribute too. This will then only affect a single smallipop, which helps you customizing single smallipops without creating different calls for each configuration.

Hover me!
<span class="smallipop" data-smallipop-preferred-position="right" title="Some text">
    Hover me!
</span>
Key Default value Description
autoscrollPadding 200 Visible window margin in pixels in which the tour feature tries to stay in, when showing the next or previous step in a tour.
funcEase easeInOutQuad Easing function for the animations.
handleInputs true Enables the focus and blur events on tags like input, textarea, select and disables the hide on click.
hideDelay 500 Time before popup will be hidden.
hideOnPopupClick true Hide smallipop when it is clicked.
hideOnTriggerClick true Hide smallipop when the trigger is clicked.
hideTrigger false Hide the trigger when the popup is shown.
infoClass smallipopHint Class in an element which contains markup content for the popup.
invertAnimation false The popup will move up when an element is hovered and further up when fading out. If you set this to true, the popup will move down when fading out.
onAfterHide null Callback after smallipop is hidden
onAfterShow null Callback after smallipop is shown
onBeforeHide null Callback before smallipop is hidden
onBeforeShow null Callback before smallipop is shown
onTourClose null Callback when the tour has finished
onTourNext null Callback when the next tour element is shown
onTourPrev null Callback when the previous tour element is shown
popupAnimationSpeed 200 How much time the popup needs to reach it's final animation position and opacity in milliseconds.
popupDelay 100 How much time in milliseconds you have to hover on an element before the popups shows up.
popupDistance 20 Vertical distance when the popup appears and disappears.
popupOffset 31 Horizontal offset for the popup from the center of the trigger when the popup is aligned left or right.
popupYOffset 0 Vertical offset for the popup.
preferredPosition top Use "top" or "bottom" for the default layout and "left" or "right" when the popup should stay horizontal.
theme default black, blue, white and a default theme are included in the css file.
touchSupport true When touch events are supported hover events are disabled and smallipop will activated by touching a trigger.
A second touch will trigger the default action on the trigger. I.e. open a link. The touch feature detection currently requires the modernizr library.
triggerAnimationSpeed 150 How fast the trigger fades in and out when hideTrigger is set.
triggerOnClick false Disables the hover event for triggers and smallipop will be activated by clicking the trigger.
A second click will trigger the default action on the trigger. I.e. open a link.
windowPadding 30 Minimal distance to the window borders the smallipop should keep when computing it's orientation.

Callable methods

You can show and hide smallipop via manual calls. Only the first element found in the selectors result will be triggered.

$('.myTrigger').smallipop('show');
$('.myTrigger').smallipop('hide');

Removing smallipop from elements is also possible.

$('.myTriggers').smallipop('destroy');

Update the content of a smallipop while it's visible.

$('.myTrigger').smallipop('update', 'Test');

Installation

Prequisites

Both are also provided in the lib folder. If you don't want to use the Modernizr library and want to save space you can remove the
.cssgradients, .borderradius, .rgba and .boxshadow classes in css/jquery-smallipop.css.


Required files

1. Copy lib/jquery-smallipop.js to your javascript folder.

2. Copy lib/jquery-x.x.x.min.js to your javascript folder if you don't use jQuery already.

3. Copy lib/modernizr-x.x.x.js to your javascript folder if you don't use modernizr already.

4. Copy css/jquery-smallipop.css to your css folder.

5. Copy css/animate.min.css to your css folder if you want to use the advanced css based animations.

There is a minified version of the smallipop javascript for production in the lib folder too.


Modify your html header

Add these lines to the header of your html file and replace x.x.x with the correct versions

<link rel="stylesheet" href="css/jquery-smallipop.css" type="text/css" media="all" title="Screen"/>
<script type="text/javascript" src="lib/jquery-x.x.x.min.js"></script>
<script type="text/javascript" src="lib/modernizr-x.x.x.min.js"></script>
<script type="text/javascript" src="lib/jquery-smallipop.js"></script>

Features

  • Small
    Only ~ 12KB minified and even less when gziped by your server.
  • Pure css
    No images but fallbacks for older browsers.
  • Compatibility
    smallipop has been tested with IE7-9, Chrome, Safari 4+,
    Opera and Firefox 4+
  • Custom themes
    For different use cases.
  • Free positioning
    The popup code will be added to the document root so the
    position won't be affected by your layout.
  • Automatic orientation
    The popup will try to stay in the visible area of the screen,
    even when scrolling or at the edges.
  • Only a single popup element
    Some plugins create a hidden popup for each trigger.
  • Custom options for each trigger
    You can have 20 different popups with 20 different themes
    on one page if you like.
  • Licensed under the MIT license.

We are using this plugin for a lot of things, so watch for new releases at github.

New and improved in this version
  • NEW Icon for closing the tour.
  • NEW Compatibility with jQuery 1.9.
  • CHANGE Smallipop won't scroll the window when the trigger has a fixed position.

+ Click here to see changes in the last versions

  • 0.3.5
    • CHANGE Fixed position for the popup when the trigger is having a parent with a fixed position.
  • 0.3.2
    • NEW Control the tour with arrow keys
    • NEW Inline hint is now preferred to title attribute for tooltip content
    • NEW Use 'data-smallipop-referenced-content'-attribute to display updateable referenced content
    • NEW Option 'hideDelay' to customize time before the popup is hidden
    • FIX Javascript error when showing smallipop after deleting the last shown hint
  • 0.3.1
    • NEW The tour feature!
    • NEW Customize each smallipop via the data attribute
    • NEW More callable methods
  • 0.2.0
    • NEW Support for css animations
    • NEW Special handling for form elements
    • NEW Show, hide and destroy methods can be called directly on triggers
    • NEW Callbacks for show and hide events
    • NEW Update content on the fly via the setContent method
    • INFO A lot of code cleanup, refactoring, namespacing and stuff
  • 0.1.6
    • FIX "invalid argument" error in IE8 sometimes happening
  • 0.1.5
    • Added funcEase option to set your own easing function for the animations. (See the options)
    • Added touch support which disables the hover events and uses the click event on touch capable devices.
      Can be disabled with the touchSupport option.
    • Added triggerOnClick option to force disable the hover events and just listen for the click event on your triggers.
    • Window padding can now be changed with the windowPadding option.
      Smallipop tries to keep this distance from the window borders.
  • 0.1.4
    • Added option to define the animation easing function.
    • Added options for triggers to show the smallipop on click instead of hover.
    • Automatic touch device support which uses touch events instead of hover. Can be disabled.

Dependencies
  • jQuery version 1.5.2 or better
  • Modernizr for browser capability fallbacks.
    The library is included in the plugins lib folder.


Have fun and check out my other plugins

jQuery Rondell


Feedback is welcome!

Please send me suggestions, ideas for improvement or anything else to [email protected] or @sebobo


© 2012 by Small Improvements


Smallipop is powered by coffeescript and sass.
